CTC 100 Profile
Key features
• 100W COB white LED
• 2700K - 6000K color temperature
• CRI over 90
• HD optical system, clean shutter cuts beam
• 15° - 30° or 25° - 50° zoom lens optional, single side zoom
• Flicker free with selectable PWM
• Rotary, key, DMX control of dimmer
• Intelligent fan, silent operation for studio and theatre use
• Super compact body, only 3.5 kg, easy to install and setup
• IP rated powercon in, DMX in & out
CTC 100 Profile is a 100W tunable LED profile spot. With 15° - 30° or 25° - 50° zoom lens optional, Color temperature 2700K - 6000K. Compact body, easy to set up. It’s an idea product for art gallery, museum, shoping mall.
Product Specifications
CTC 100 Profile Physical
Size: 459 x 221 x 342mm (L x W x H)
Net Weight: 3.5 kg
Gross Weight: 5 kg
CTC 100 Profile Dynamic Effects
Electronic shutter effect: Instant open and blackout
Electronic dimming: 0 - 100%, dimming curve selectable
Strobe effects
CTC 100 Profile Control and Programming
Control protocol: DMX, RDM, Rotary
Setting and addressing: Control panel with LCD display
DMX channels: 2/5
Dimmer frequency: 1.2 - 24.0KHz
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
CTC 100 Profile Optics
Light source: 100Watt white LED
Color temperature: 2700K - 6000K tunable
Lens tube: 15° - 30° or 25° - 50° zoom lens
LED lifetime: 50,000 hours
CTC 100 Profile Photometric Data
CRI (Color Rendering Index) : >90
CTC 100 Profile Construction
Housing: Engineering plastic
Color: Black
Protection rating: IP20
Gobos and color frame
Gobo size : OD 38mm
Installation
Mounting: Adjustable bracket
Location: Indoor use only
Orientation: Any
CTC 100 Profile Connections
AC power in, thru: IP rated powercon in
DMX and RDM data in/out: 3-pin XLR in & out
CTC 100 Profile Electrical
AC power: 100-240 V nominal, 50/60 Hz
Power consumption figures are typical, not maximum. Allow for +/- 10% variation.
CTC 100 Profile Thermal
Cooling: Heat sink + Intelligent fan(low noise)
Maximum ambient temperature (Ta max.): 45° C
Minimum ambient temperature (Ta min.): -5° C
CTC 100 Profile Included Items
Power input cable
Safety cable
User manual
Color frame
CTC 100 Profile Accessories Optional
Gobo Holder
Clamp
