Event 100T
Key features:
• 200W LED ( 100W WW + 100W CW )
• 2700K - 6000K color temperature.
• Average CRI 95, TLCI 96.
• 25° - 60° zoom lens, single side zoom.
• Flicker free with selectable PWM.
• Rotary, key, DMX control of dimmer.
• Intelligent fan, silent operation for studio and theatre use.
• Super compact body, only 2.5 kg, easy to install and setup.
• Powercon TR1 in, DMX in & out.
EVENT 100T is a tunable white LED fresnel light with zoom. Event 100T It’s powered by 100W 2700K - 6000K LED source and zoom lens. The fixture comes with average high CRI over 95, TLCI over 96. Barndoor and color frame is included in delivery. The fixture is super compact for small exhibitions.
• Event 100T is 200W LED ( 100W WW + 100W CW )
• 2700K - 6000K color temperature.
• Average CRI 95, TLCI 96.
• 25° - 60° zoom lens, single side zoom.
• Flicker free with selectable PWM.
• Rotary, key, DMX control of dimmer.
• Intelligent fan, silent operation for studio and theatre use.
• Super compact body, only 2.5 kg, easy to install and setup.
• Powercon TR1 in, DMX in & out.
Event 100T
Product Specifications
Event 100T Physical
Size: 403 x 180 x 124mm (L x W x H)
Net Weight: 2.5 kg
Dynamic Effects
Electronic shutter effect: Instant open and blackout
Electronic dimming: 0 - 100%, dimming curve selectable
Strobe effects
Control and Programming
Control protocol: DMX, RDM
Setting and addressing: Control panel with digital display
DMX channels: 1/2/3/5
Dimmer frequency: 1.2 - 24.0KHz
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Optics
Light source: 200Watt LED ( 100W WW + 100W CW )
Color temperature: 2700K- 6000K adjustable
Zoom: 25° - 60° manual zoom
LED lifetime: 50,000 hours
Photometric Data
CRI (Color Rendering Index) : >95
Construction
Color: Black
Protection rating: IP20
Installation
Mounting: Adjustable bracket
Location: Indoor use only
Orientation: Any
Connections
AC power in, thru: PowerCON in
DMX and RDM data in/out: 3-pin XLR in & out
Electrical
AC power: 100-240 V nominal, 50/60 Hz
Power consumption figures are typical, not maximum. Allow for +/- 10% variation.
Thermal
Cooling: Heat sink + fan(low noise)
Maximum ambient temperature (Ta max.): 45° C
Minimum ambient temperature (Ta min.): -5° C
Event 100T Included Items
Power input cable
Safety cable
User manual
Color frame
Barndoor
