Solar Panel 300T

KEY FEATURES:

•1440 * 0.2W WW + 1440 * 0.2W CWLED
• 3200K - 5600K tunable
• Super bright, uniform coverage
• Super silent operation for all circumstances
• High CRI 95, TLCI 98
• Support DMX and RDM protocols
• Dimmer curves selectable
• Smooth dimming, flicker free operation
• Rotary control of dimmer and color temperature
•Dimmer frequency 1.2 - 24.0 KHz
• 8 - leaf barn door

APPLICATION:

• Broadcast, TV studio
• Film shooting
• Video shooting

PHYSICAL

Size: 652 x 150 x 299mm

Net Weight: 9.5 kg(barndoor incl.)

DYNAMIC EFFECTS

Electronic shutter effect: Instant open and blackout

Electronic dimming: 0 - 100%, dimming curve selectable

CONTROL AND PROGRAMMING

Control protocol: DMX, RDM, stand-alone

Setting and addressing: Control panel with LCD display

DMX channels: 2 / 5

Dimmer frequency: 1.2 - 24.0 KHz

DMX compliance: USITT DMX512-A

RDM compliance: ANSI/ESTA E1.20

OPTICS

Light source: 1440 * 0.2W WW + 1440 * 0.2W CWLED

Color temperature: 3200K(WW) - 5600K(CW) tunable

LED lifetime: 50,000 hours

PHOTOMETRIC DATA

CRI (Color Rendering Index) : >96

CQS (Color Quality Scale): >94

TM-30 Rf (IES TM-30-15 Fidelity Index): >91

TM-30 Rg (IES TM-30-15 Gamut Index): >100

TLCI (Television Lighting Consistency Index): >98

CONSTRUCTION

Housing: Aluminum

Color: Black

Protection rating: IP20

INSTALLATION

Mounting: Adjustable bracketLocation: Indoor use only

Orientation: Any

CONNECTIONS

AC power in, thru: PowerCON

DMX and RDM data in/out: 3-pin locking XLR

ELECTRICAL

AC power: 100-240 V nominal, 50/60 Hz

TYPICAL POWER

230 V, 50 Hz: 300 W

Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.

THERMAL

Cooling: Heating sink

Maximum ambient temperature (Ta max.): 45°C

Minimum ambient temperature (Ta min.): 5° C

INCLUDED ITEMS

Power input cable (0.75mm2, 18 AWG), bare ends to powercon (female), 1.5 m (4.9 ft.)
Mounting bracket
8-leaf barn door
User manual

Accessories optional:

Clamp
Beehive diffuser
